P1382 Honda

P1382 Honda - Cylinder Position Sensor 1 No Signal

PDF
P1382 Honda Comments |  Add Comment
Possible causes
- Cylinder Position Sensor harness is open or shorted
- Cylinder Position Sensor circuit poor electrical connection
- Faulty Cylinder Position Sensor
Help with Possible causes What does this mean?
Tech notes
The Cylinder Position (CYP) Sensor, Crankshaft Position Sensor (CKP) and Top Dead Center (TDC) Sensor are all built into the distributor.
Help with Tech Notes What does this mean?
When is the code detected?
If no cylinder position (CYP) sensor pulsing signals are detected, a malfunction is detected and a the P1382 code is stored.
Possible symptoms
- Engine Light ON (or Service Engine Soon Warning Light)
P1382 Honda Description

The cylinder position (CYP) sensor consists of a rotor and a pick-up coil that detects rotor position. When the rotor turns after starting the engine, the changes of magnetic flux in the pick-up coil are converted into pulsing signals to the engine control module (ECM)/powertrain control module (PCM). The CYP sensor detects the position of the No.1 cylinder for sequential fuel injection.
